70113-001 Ripple Pattern Sandwich Panel
Description
Reviews
Carved metal external wall insulation board by 70113-001 Ripple Pattern Sandwich Panel is widely used for interior wall and Exterior wall
· 3 layers:
· Surface: 0.3 mm Al-zn alloy coated steel sheet (Al 55%, Zn 43%)
· Middle: 16mm PU foam
· Back : Aluminium foil paper
· Size: Length (3000mm-6000mm) * Width:380mm * Thickness: 16mm
· Weight: 3.7kgs/sqm
Baikal Sandwich panel is widely used for Exterior wall cladding and Interior wall Insulation and Decoration in the filed of PEB house, Villa, Steel Structure buildings, Hospital, Old Building renovation, School, Library, Supermarket, Plant, Train Station, Residence and so on!
1. Decoration & beautify
Free combination of different color with different pattern can produce hundreds of styles, make your building much more attractive to your customers.
2. Thermal &; Insulation
Thermal Conductivity: 0.021 W/(m·K)
Thermal resistance: 0.648 (m2·K)/W
3°~5° difference inside & outside after using Baikal sandwich panels.
3. Water proof & Fire proof
It is the basic Characteristic for exterior wall panel, for the surface is Galvanized steel sheet, inner side is Aluminium foil paper, good water resistance & fire resistance.
4. Energy-saving
Energy saving: air condition usage=1/3--1/5 energy before install panel
16mm Baikal sandwich panel =500mm common brick=1200mm mortar
5. No rust, No fade, Long lifetime.
Al 55% + 43% Zn Alloy steel sheet on the panel surface! This good chemical performance identified by World & Steel Institute make the sandwich panel lifetime more than 40 years.
6. Light weight
Weight 3.7kgs/sqm, lighten building self-weight, so very hot selling for steel structure building, PEB house.
7. Easy installation
Just insert one by one and fix by screw, very easy!
About 30 sqm per person per day average, so widely used for speed house.
8. Eco-friendly
Dry construction, no need water, no need concrete, no dust, no, Pollution, no noise.
9. Easy Maintenance
Self-cleaning by rain or water
We can provide the following 13 pattern PU sandwich panels
1. Small Brick Pattern Sandwich Panel
2. Big Brick pattern Sandwich Panel
3. Stone Pattern Sandwich panel
4. Tile Pattern Sandwich Panel
5. Mosaic Pattern Sandwich Panel
6. Marble Pattern Sandwich Panel
7. Wood Pattern Sandwich Panel
8. Wave Pattern Sandwich Panel
9. Small Stone Pattern Sandwich Panel
10. Brick Pattern Sandwich Panel
11. Big Stone Pattern Sandwich Panel
12. Flat Pattern Sandwich Panel
13. Ripple Pattern Sandwich Panel
Baikal Sandwich panel Physical Testing Data
Baikal Sandwich Panel Flame Retardant of Polyurethance Foam
Baikal Sandwich Panel Heat Insulation Comparision
